China factory direct sale rotary lawn mower
Features of M1503 Rotary Lawn Mower
1. The 20' lawn mower has excellent chopping ability. Cutting width 6.1m
2. Can accommodate 30”, 32”, 26”, 38” row spacing.
3. Excellent shredding and distributing ability of fixed knife group
4. Unique driving layout, each lower box is equipped with a clutch.
5. The bottom surfaces of all units form a plane
6. Use rubber pads as rear suspension floating shock absorbers
7. Parallel lift cutting system.
8. Non-adjustable clutch provides low maintenance.
9. The 300hp 50-degree distribution gearbox allows for a unique drivetrain layout.
Product parameter
SPECIFICATIONS |
M2005 |
Cutting Width |
6100mm |
Overall Width |
6500mm |
Overall Length |
6100mm |
Transport Width |
2650mm |
Transport Height |
3000mm |
Weight(depending on configuration) |
2990kg |
Hitch Weight(depending on configuration) |
1040kg |
Minimum Tractor HP |
100hp |
Recommended Tractor HP |
120hp |
Cutting Height(depending on configuration) |
30-300mm |
Ground Clearance |
300mm |
Cutting Capacity |
51mm |
Blade Overlap |
120mm |
Number of tools |
20EA |
tyres |
6-185R14C/CT |
Wing Working Range |
-20°~103° |
Wing Floating Range |
-20°~40° |
FAQ
Q1: Does the BROBOT mower have a cooling gearbox?
A1: Yes, the BROBOT lawn mower is equipped with a cooling gearbox.
Q2: What is the purpose of the wing anti-detachment device?
A2: The wing anti-off device is used to prevent the mower wings from falling off during operation.
Q3: What is the keyway bolt design for?
A3: Keyway bolts are designed to prevent the bolt from loosening during operation.
Q4: Is the safety chain easy to remove?
A4: Yes, the safety chain is designed to be easily removable.
Q5: How many gearbox layouts does BROBOT mower have?
A5: There are 6 gearbox layouts for BROBOT mowers.
Q6: Does the BROBOT mower have anti-skid locks?
A6: Yes, BROBOT mower has 5 anti-skid locks.
Q7: What is the layout of the rotor for?
A7: The layout of the rotors is designed to increase the efficiency of large mowers in the field.
Q8: Does the BROBOT mower help reduce fuel consumption?
A8: Yes, BROBOT mowers are designed to reduce fuel consumption.
